High Frequency Mud Linear Vibrating Screen Washing Dewater Soil Removing Classifier

  • 1
  • 2

Brand Name : PK

Model Number : ZS

Certification : CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification

Place of Origin : Xinxiang City, Henan Province,China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 1000SETS/YEAR

Delivery Time : AOUT 30 DAYS

Packaging Details : Standard export package

Mesh Type : Woden Wire Mesh

Capacity : 3~120m3/h

Power : 0.37*2~7.5*2(kw)

Mesh Material : Stainless Steel or Polyurethane

Warranty : 18 months

Surface Treatment : Sa2.5

Paint : Polyurethane Mesh

Driven device : 2 Vibrating motors

Contact Now

High Frequency Mud Linear Vibrating Screen Washing Dewater Soil Removing Classifier


Introduction

Stainless steel dewatering screen is mainly composed of screen box, vibration exciter, supporting system and motor. The machine adopts double motor self-synchronization technology, universal eccentric block and adjustable amplitude vibrator.
The two unrelated vibrators run synchronously and inversely, and the centrifugal forces produced by the two groups of eccentric masses are superimposed along the vibration direction and counteracted by reverse centrifugation, thus forming a single excited vibration along the vibration direction, which makes the screen box move in a reciprocating straight line.


Advantages and Feathers
1. Advanced structure, small volume, light weight, high efficiency, low noise, adopt new type of vibration motor as the direct drive, low investment cost
2. Screen has a simple structure, easy maintenance. Screen adopts high strength metal woven mesh, durable service, or uses polyurethane screen mesh.
3. It has seat type and hanging type for choice.
4.Open baffle at feeding position of the screen frame, increase the process capacity of raw material
5.Polyurethane screen as sieve surface, durable wear, corrosion resistance, long life
6.Hook belt fastening, sifting side plate reinforcement, strong and durable
7. Rubber soling shock absorption, low noise
8. Customize double layer screen, mesh hole size, stainless steel screen, galvanized screen for specific use


Technical Data

Model

Screen
Area
(m2)

Mesh
Size
(mm)

Feeding
Size
(mm)

Frequency
(r/min)

Amplitude
(mm)

 Motor

Power
(Kw)

Capacity
(t/h)
ZSM1542 6 0.25-13 ≤300 800 9-10 Y160M-4 11 30-60
ZSM1556 8 13-50 ≤300 800 10 Y160L-4 15 30-60
2ZSM1556 8

U:13-50
L:0.25-13

 ≤300 800 11 Y160L-4 15 30-60
ZSM1556B 8 13-50 ≤300 800 11 Y132M-4 7.5×2 30-60
2ZSM1556B 8 U: 13-50
L:0.25-13		 ≤300 800 11 Y132M-4 7.5×2 30-60
ZSM1756A 9.5 13-50 ≤300 800 10 Y160L-4 15 50-80
2ZSM1756 9.5 U:13-50
L:0.25-13		 ≤300 800 10 Y160L-4 15 50-80
ZSM1756B 9.5 13-50 ≤300 800 10 Y132M-4 7.5×2 50-80
2ZSM1756B 9.5 U:13-50
L:0.25-13		 ≤300 800 10 Y132M-4 7.5×2 50-80
ZSM1856 10 13-50 ≤300 800 11 Y160M-4 11 50-80
ZSM2065 13 13-50 ≤300 800 11 Y180M-4 18.5 70-100
2ZSM2065 13 U:13-50
L:0.25-13		 ≤300 800 1 Y180M-4 18.5 70-100
ZSM2065B 13 13-50 ≤300 800 9 Y160L-4 11×2 70-100
2ZSM2065B 13 U:13-50
L:0.25-13		 ≤300 800 11 Y160L-4 11×2 70-100

High Frequency Mud Linear Vibrating Screen Washing Dewater Soil Removing Classifier
Selection Conditions

♦ Material to be processed:

♦ Screen layer/deck/sieve number:

♦ Bulk density:
t/m3

♦ Mesh size of every screen layer/deck/sieve:
mm

♦ Material Temperature:
ºC

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Water Content:
%

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:
(Yes or No)

 ♦ Drive: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:
(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:
mm

♦ Working environment:
(indoor or outdoor)

♦ Max. granule size:
mm

♦ Working environment temperature:
°C

♦ Particle distribution percentage:

♦ Working power supply:
3 Phase V Hz

♦ Handling capacity:
t/h

♦ Quantity:
sets
